Detecting sub-millimeter solder bridges and component misalignment requires a vision system capable of extreme close-up focus and high resolving power. The 0.05 m Minimal Object Distance (M.O.D.) allows the camera to be positioned intimately close to the board, while the 1.90 µm minimal pixel pitch captures microscopic defects. The 12.00 MP resolution ensures a wide inspection area without losing detail, and the fixed 5.6 aperture provides a deep enough depth of field to keep varying 3D component heights in sharp focus simultaneously.

Amber glass and colored plastics often obscure visible light, making internal contamination inspection highly challenging. Because this lens has no IR cut filter ('IR cut filter: no'), it allows the use of near-infrared (NIR) backlighting to easily penetrate colored glass. The compact 8.0 mm focal length permits the vision system to be installed in heavily space-constrained conveyor areas, while the 1/1.7" maximal image circle ensures the full width of the vial is captured for high-throughput inspection.

Metrology applications demand highly repeatable image capture without mechanical or optical variability. The fixed F/5.6 aperture ensures perfectly consistent light throughput and optimal edge sharpness across the frame without the mechanical iris shift found in adjustable lenses. The 49.3° x 38.1° Angle of view tightly frames the gaskets from a short distance, and the 12.00 MP optical resolution guarantees that sub-pixel deviations in the gasket's geometric profile are accurately measured to maintain strict ISO tolerances.
