1. Automotive Paint Shop Cartesian Robot Coupling
Couples a 60H motor to an S48 linear actuator on a multi-axis Cartesian robot used for automated automotive paint spraying and sealant dispensing [1.9].
Problem SolvedEliminates the risk of paint defects caused by silicone or other contaminants, as the kit complies with VDMA24364-B2-L (PWIS/LABS) standards, while safely transmitting up to 12.5 Nm of torque for precise positioning.
VDMA24364-B2-LPWIS conformity12.5 Nm torqueS48 actuator interface
2. High-Speed Electronics Pick-and-Place Gantry
Integrates the motor mounting kit into a highly dynamic component handling machine operating within a dry, indoor electronics assembly plant.
Problem SolvedMinimizes system lag and mechanical stress during rapid acceleration cycles. Its extremely low mass moment of inertia of 5.87 kgmm² and lightweight profile of 340 g easily support motor speeds up to 8000 rpm, while the IP40 rating perfectly suits dry environments.
8000 rpm rotational speed5.87 kgmm² mass moment of inertiaIP40 degree of protection340 g product weight
3. Automated Warehouse Sorting Conveyor Diverter
Employs the axial kit to connect drive motors and mechanical linear actuators that push and divert packages across conveyor lanes in a large-scale logistics center.
Problem SolvedGuarantees reliable mechanical power transmission in fluctuating, non-climate-controlled warehouse conditions by operating flawlessly across an ambient temperature range of -10 °C to 60 °C and enduring up to 95% relative air humidity.
-10 °C to 60 °C ambient temperature0 - 95% relative air humidity60H motor interface12.5 Nm transmittable torque
