Festo ADVU-16-20-P-A Compact Pneumatic Cylinder

Technical Overview

The Festo ADVU-16-20-P-A (Part No. 156510) is a high-performance, double-acting compact pneumatic cylinder engineered for space-constrained industrial environments. Featuring a 16 mm piston bore and a 20 mm stroke length, this actuator delivers a robust theoretical advance force of 121 N and a return force of 90 N at an operating pressure of 6 bar. Constructed with a wrought aluminum alloy barrel and a high-alloy stainless steel piston rod (with an M4 female thread), it ensures excellent durability and moderate corrosion resistance (CRC 2). The cylinder integrates flexible elastic cushioning rings at both ends to mitigate impact energy (up to 0.1 J) and features an integrated magnetic piston for precise position sensing via proximity sensors. Operating efficiently between 1.2 and 10 bar using M5 pneumatic connections, the ADVU series is optimized to require up to 50% less installation space than standard ISO 15552 cylinders.

Key Features

Compact design requiring up to 50% less installation space compared to ISO 15552 cylinders
Double-acting mode of operation with a 16 mm bore and 20 mm stroke
Flexible elastic cushioning rings/plates at both ends to absorb impact energy
Integrated magnetic piston for compatible proximity sensor position detection
High-alloy stainless steel piston rod featuring an M4 female thread
M5 pneumatic connections with a wide operating pressure range of 1.2 to 10 bar
Constructed with a wrought aluminum alloy cover and barrel with NBR/TPE-U dynamic seals

Technical Specification Matrix

Parameter	Value
Bore Size (Piston Diameter)	16 mm
Stroke Length	20 mm
Operating Pressure	1.2 to 10 bar (17.4 to 145 psi)
Pneumatic Connection	M5
Piston Rod Thread	M4 Female
Mode of Operation	Double-acting
Theoretical Force at 6 bar (Advance)	121 N
Theoretical Force at 6 bar (Return)	90 N
Ambient Temperature	-20 °C to 80 °C
Cushioning	Elastic cushioning rings/plates at both ends
Corrosion Resistance Class (CRC)	2 - Moderate corrosion stress
Basic Weight	89 g

Industrial Applications

1. Confined-Space Automated Clamping

Utilizing its ultra-compact footprint—requiring 50% less space than standard ISO cylinders—and a solid 121 N advance force at 6 bar, this cylinder effectively actuates clamps for miniature workpieces in dense automation cells or custom machining fixtures.

Problem Solved

Resolves the engineering challenge of integrating reliable holding force into tightly confined machine cavities where traditional actuators are too bulky.

Compact Cylinder121 N Advance ForceDouble-actingConfined Space Clamping

2. High-Cycle Sorting and Ejection Arrays

In high-speed packaging and quality control lines, the ADVU-16-20-P-A is used to trigger diverter gates or eject rejected items. Its elastic cushioning on both ends successfully absorbs up to 0.1 J of impact energy, preventing mechanical wear.

Problem Solved

Prevents premature failure of lightweight pneumatic components during continuous, high-speed automated sorting operations by utilizing dual-end elastic cushioning to mitigate repeated impact stress.

Elastic CushioningImpact Energy 0.1 JProximity SensingHigh-Cycle Pneumatics

3. Precision Electronics Assembly Pressing

Fitted with an M4 female threaded piston rod and built for a precise 20 mm stroke, this cylinder performs light, highly repeatable pressing, seating, and insertion tasks for printed circuit boards or consumer electronics.

Problem Solved

Provides reliable linear motion with a moderate, strictly controllable force profile (90-121 N) that allows for the damage-free seating of delicate electronic components in automated stations.

M4 Female Thread20 mm Stroke16 mm BorePrecision Assembly Press
