$ 22.31
| Main | |
| Part Number | XB4BD33 |
| Product Series | Harmony XB4 |
| product type | Selection switch |
| product short name | XB4 |
| frame material | Nickel plated metal |
| Retaining ring material | Zamak |
| Installation diameter | 22 mm |
| Quantity sold separately | 1 |
| Control head type | Standard |
| Signal unit head shape | Round |
| Operating head type | Locking |
| joystick shape | Black short handle |
| Operating head position information | 3 positions +/- 45° |
| contact type | 2 NO |
| contact action | Slow break |
| Wiring capacity | Screw-on, <= 2 x 1.5 mm² with wire terminals to EN/IEC 60947-1 |
| Screw-on, >= 1 x 0.22 mm² without wire terminals to EN/IEC 60947-1 | |
| Additional information | |
| high | 47 mm |
| width | 30 mm |
| depth | 68 mm |
| ISO n°1 terminals | (23-24)NO |
| (13-14)NO | |
| Product Weight | 0.105kg |
| High pressure washer resistance | 7000000 Pa at 55 °C, distance: 0.1 m |
| Wire use | Standard contact |
| force open | None |
| torque | 0.14 Nm NO change electrical state |
| Mechanical life | 1000000 times |
| Tightening torque | 0.8…1.2 Nm conforming to EN 60947-1 |
| screw head shape | Cross compatible with Philips no 1 screwdriversCross |
| compatible with pozidriv No 1 screwdriversSlotted | |
| compatible with flat Ø 4 mm screwdriversSlotted | |
| compatible with flat Ø 5.5 mm screwdrivers | |
| contact material | Silver Alloy (Silver/Nickel) |
| Short circuit protection | 10 A Cartridge fuse type gG conforming to EN/IEC 60947-5-1 |
| Conventional thermal current [Ith] | 10 A conforming to EN/IEC 60947-5-1 |
| Rated insulation voltage [Ui] | 600 V (pollution degree 3) according to EN 60947-1 |
| Rated impulse withstand voltage [Uimp] | 6 kV according to EN 60947-1 |
| Rated operating current [Ie] | 3 A at 240 V, AC-15, A600 conforming to EN/IEC 60947-5-1 |
| 6 A at 120 V, AC-15, A600 conforming to EN/IEC 60947-5-1 | |
| 0.1 A at 600 V, DC-13, Q600 conforming to EN/IEC 60947-5-1 | |
| 0.27 A at 250 V, DC-13, Q600 conforming to EN/IEC 60947-5-1 | |
| 0.55 A at 126 V, DC-13, Q600 conforming to EN/IEC 60947-5-1 | |
| 1.2 A at 600 V, AC-15, A600 conforming to EN/IEC 60947-5-1 | |
| Electrical life | 1000000 cycles, AC-15, 2 A at 230 V, operating rating <3600 cycles/hour, duty factor: 0.5 according to EN 60947-5-1 Annex C 1000000 cycles, AC-15, 3 |
| A at 120 V, operating rating <3600 cycles/hour, duty factor: 0.5 conforming to EN 60947-5-1 Annex C | |
| 1000000 cycles, AC-15, 4 A at 24 V, operating rating <3600 cycles/hour, duty factor : 0.5 conforming to EN 60947-5-1 Annex C | |
| 1000000 cycles, DC-13, 0.2 A at 110 V, duty rating <3600 cycles/hour, duty factor: 0.5 conforming to EN 60947-5-1 Annex C 1000000 | |
| cycles , DC-13, 0.5 A at 24 V, operating rating <3600 cycles/hour, duty factor: 0.5 conforming to EN 60947-5-1 Annex C | |
| electrical reliability | Λ < 10exp(-6) at 5 V and 1 mA at clean ambient conforming to EN/IEC 60947-5-4 |
| Λ < 10exp(-8) at 17 V and 5 mA at clean ambient conforming to EN/IEC 60947-5-4 IEC 60947-5-4 | |
| Equipment introduction | Product (not parts) |
| environment | |
| Protective treatment | TH |
| storage environment temperature | -40…70°C |
| operating temperature | -40…70°C |
| Type of overvoltage | Class I conforms to IEC 60536 |
| IP protection class | IP69 |
| IP69K | |
| IP67 conforming to IEC 60529 | |
| NEMA degree of protection | NEMA 13 |
| NEMA 4X | |
| Standards compliant | EN/IEC 60947-5-4 |
| UL 508 | |
| EN/IEC 60947-5-1 | |
| EN/IEC 60947-5-5 | |
| JIS C8201-5-1 | |
| EN/IEC 60947-1 | |
| CSA C22.2 No 14 | |
| JIS C8201-1 | |
| certified product | GL |
| UL | |
| LROS (Lloyds register of shipping) | |
| CSA | |
| BV | |
| DNV | |
| Anti-vibration | 5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6 |
| impact resistance | 30 gn (duration = 18 ms) for half-sine shocks according to IEC 60068-2-27 |
| 50 gn (duration = 11 ms) for half-sine shocks according to IEC 60068-2-27 | |
| packaging unit | |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.5cm |
| Package 1 Width | 5.4 cm |
| Package 1 Length | 9cm |
| Package 1 Weight | 104g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 5 |
| Package 2 Height | 8.8cm |
| Package 2 Width | 3.4cm |
| Package 2 Length | 26.5cm |
| Package 2 Weight | 520g |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 100 |
| Package 3 Height | 30cm |
| Package 3 Width | 30cm |
| Package 3 Length | 40cm |
| Package 3 Weight | 10.888kg |
| contract warranty | |
| Warranty | 18 months |
