1. High-Speed PCB Surface Mount Technology (SMT) Inspection
Utilizing the lens in an Automated Optical Inspection (AOI) system to verify the placement and soldering of micro-components on printed circuit boards.
Problem SolvedDetecting microscopic soldering defects and component misalignments without slowing down the production line. The 5.00 MP resolution and 3.45 um minimal pixel pitch ensure fine details like solder bridges are resolved accurately, while the short 0.10 m M.O.D. allows for highly compact AOI machine footprints.
5.00 MP resolution3.45 um pixel pitch0.10 m M.O.D.Automated Optical InspectionMachine Vision
2. Pharmaceutical Blister Pack Verification and Barcode Reading
Integrating the lens into a vision system on a high-speed pharmaceutical packaging line to verify pill presence and read 2D matrix codes.
Problem SolvedEnsuring zero-defect packaging in high-speed conveyor environments. The F1.6 maximum aperture allows for very short exposure times to prevent motion blur, while the 12.0 mm focal length provides the necessary 40.1-degree horizontal angle of view to capture the entire blister pack at a close working distance.
F1.6 aperture12.0 mm focal length40.1 x 30.3 degrees angle of viewHigh-speed machine vision2/3 inch optical class
3. Non-Contact Metrology for Precision Automotive Parts
Employing the lens in a robotic metrology station to measure dimensional tolerances of machined engine components directly on the assembly line.
Problem SolvedReplacing slow, contact-based measuring machines with rapid optical measurement. The lens supports up to 1/1.2 inch sensors to capture high-contrast, edge-to-edge sharp images of metallic parts, ensuring tight tolerances. The 11.89 mm back focal length ensures seamless integration with standard industrial C-mount cameras.
1/1.2 inch sensors11.89 mm back focal length5.00 MP resolutionC-mount metrology7.8 mm maximal immersion depth
