100K-step PLC CPU with built-in 100 Mbps EtherNet/IP, 2,560 I/O bits, and compact panel-mount CJ rack form factor.
CJ-series CPU unit with built-in EtherNet/IP for high-speed machine control. The CJ2H-CPU66-EIP provides 100K steps of user memory, 2,560 I/O bits, and a built-in 100 Mbps EtherNet/IP port for CIP tag data links and explicit messaging. Omron specifies panel-mount enclosure, 5 VDC current consumption of 0.82 A, ambient operating temperature 0 to 55°C, and a compact CPU rack form factor suitable for multi-rack CJ systems.
| Parameter | Value |
|---|---|
| User Memory | 100K steps |
| I/O Bits | 2,560 bits |
| Current Consumption | 5 VDC, 0.82 A |
| Ambient Operating Temperature | 0 to 55°C |
| Ambient Operating Humidity | 10% to 90% (with no condensation) |
| Enclosure | Mounted in a panel |
| Grounding | Less than 100 Ω |
| CPU Rack Dimensions | 90 mm × 65 mm × 80 mm (H × D × W) |
| Weight | 280 g or less |
| EtherNet/IP Port Speed | 100 Mbps (100Base-TX) |
| EtherNet/IP Transmission Media | Shielded twisted-pair (STP) cable; Category 5 or 5e |
| EtherNet/IP Transmission Distance | 100 m (between hub and node) |
| Communications | CIP Communications (tag data links, Explicit Messages); FINS communications |
The built-in EtherNet/IP port and 100K-step program capacity suit coordinated packaging cells that need deterministic data exchange with drives, remote I/O, and supervisory systems.
Synchronizes distributed machine modules while reducing external network gateways and CPU limitations.
The CPU’s 2,560 I/O bits and compact CJ rack architecture fit conveyor sorters with many sensors, diverters, and interlocked stations.
Handles dense discrete I/O in a small panel footprint with fast controller response.
Built-in FINS and EtherNet/IP communications make this CPU well suited for machine cells that must exchange production data with HMI, SCADA, or plant networks.
Eliminates separate communication processors for standard machine-to-host data exchange.
