USD 4,903.13
400K-step PLC CPU with built-in EtherNet/IP, 2,560 I/O bits, 0.016 μs instruction speed, USB, RS-232C, and 128 CIP connections.
CJ-series CPU unit with built-in EtherNet/IP, designed for high-capacity machine control. Official Omron documentation identifies 2,560 I/O bits, 400K-step user memory, 0.016 μs basic instruction execution, 100 Mbps EtherNet/IP, USB peripheral port, RS-232C serial port, and support for up to 128 CIP Class 3 connections. The CPU rack dimensions are 90 mm × 65 mm × 80 mm (H × D × W), and the unit weight is 280 g or less including end covers and battery. Current consumption is 5 VDC, 0.82 A.
| Parameter | Value |
|---|---|
| User memory | 400K steps |
| I/O bits | 2,560 bits |
| Mountable units | 40 units (3 expansion racks max.) |
| Basic instruction execution time | 0.016 μs min. |
| Current consumption | 5 VDC, 0.82 A |
| CPU rack dimensions | 90 mm × 65 mm × 80 mm (H × D × W) |
| Weight | 280 g or less |
| Ambient operating temperature | 0 to 55 °C |
| Ambient operating humidity | 10% to 90% (with no condensation) |
| Storage temperature | -20 to 70 °C (excluding battery) |
| Altitude | 2,000 m or less |
| Pollution degree | 2 or less |
| Noise immunity | 2 kV on power supply line |
| Overvoltage category | Category II |
| EtherNet/IP transmission speed | 100 Mbps (100Base-TX) |
| EtherNet/IP transmission media | Shielded twisted-pair (STP) cable; Category 5 or 5e |
| Peripheral port | USB 2.0-compliant B-type connector |
| Serial port interface | EIA RS-232C |
| Serial port transmission distance | 15 m max. |
| CIP communications specification | Class 3 |
| CIP Class 3 connections | 128 |
| Grounding resistance | Less than 100 Ω |
The 0.016 μs instruction time and 400K-step program capacity suit synchronized packaging machines with many interlocked axes, sensors, and recipe logic.
Maintains deterministic scan performance in dense, high-I/O packaging automation without exhausting program memory.
Built-in EtherNet/IP and 128 CIP Class 3 connections make it suitable for cells that must exchange data with drives, HMIs, remote I/O, and SCADA systems.
Eliminates the need for a separate network gateway while supporting large cyclic and explicit-message traffic.
The compact 280 g CPU with standard 5 VDC consumption, RS-232C, USB, and expansion rack support is well matched to retrofit applications needing higher memory and networking.
Upgrades existing control panels while preserving rack-based architecture and serial commissioning access.
