USD 151.55
36-in/24-out 24 VDC PLC CPU, PNP transistor outputs, 10K steps, 32K words, USB, 4 encoder inputs, 100 kHz pulse control.
DIN-rail expansion I/O unit for Omron CP-series PLC systems with 24 DC inputs and 16 transistor outputs. The module supports 24 VDC-class inputs, sinking transistor outputs, and compact panel mounting for machine control signal expansion.
| Parameter | Value |
|---|---|
| Type of module | Digital I/O |
| Number of digital inputs | 24 |
| Digital input type | PNP/NPN |
| OFF/ON delay | 0.1-1 ms |
| Permitted voltage at input | 20.4-26.4 V |
| Number of digital outputs | 16 |
| Digital output type | NPN |
| Output current | 0.3 A |
| Permitted voltage at output | 4.5-30 V |
| Product Height (unpacked) | 90 mm |
| Product Width (unpacked) | 150 mm |
| Product Depth (unpacked) | 50 mm |
| Product Weight (unpacked) | 320 g |
| Mounting style | DIN rail mount |
| Output type | Transistor |
| Display type | LED |
Adds 24 discrete inputs and 16 transistor outputs to a CP-series controller while keeping cabinet footprint small at 150 × 90 × 50 mm.
Expands control-point count without redesigning the panel or moving to a larger PLC platform.
The short 0.1–1 ms switching delay supports fast sensor-to-actuator logic for packaging and indexing machines.
Reduces latency in time-sensitive discrete control loops.
Supports 24 VDC-class input circuitry and 4.5–30 V transistor output switching for standard industrial control wiring.
Provides a straightforward interface between 24 VDC sensors, PLC logic, and low-power actuators.
