24 VDC compact PLC CPU, 18 DI/12 PNP DO, 8K steps, RS-232C/RS-485/USB, 30-point standard model.
Compact standard-model PLC CPU unit with 24 VDC supply, 18 digital inputs, 12 transistor sourcing outputs, and 8K-step program capacity. Manufacturer and distributor sources identify it as a CP2E standard-type unit with serial RS-232C, serial RS-485, and USB communication ports, plus built-in encoder input capability. The product is the 30 I/O-point DC version in the CP2E family, intended for compact machine control applications requiring source-type transistor outputs and low-voltage control wiring.
| Parameter | Value |
|---|---|
| Supply voltage | 24 VDC |
| Operating voltage range | 20.4 to 26.4 VDC |
| Digital inputs | 18 |
| Digital outputs | 12 |
| Output type | Transistor (sourcing) |
| Program capacity | 8K steps |
| Data memory capacity | 8K words |
| Logic execution time | 0.23 µs |
| Communication ports | Serial RS-232C, Serial RS-485, USB |
| Number of Ethernet ports | 0 |
| Number of USB ports | 1 |
| Number of RS-232 ports | 1 |
| Number of RS-485 ports | 1 |
| Number of encoder input channels | 6 |
| Max. encoder input frequency | 100 kHz |
| Dimensions (H × D × W) | 90 mm × 80 mm × 130 mm |
| Weight | 580 g max. |
The 24 VDC supply, 18 inputs, 12 sourcing outputs, and compact 90 × 80 × 130 mm body suit small packaging skids with limited panel space.
Provides dense I/O and a small enclosure footprint for tight control panels.
Built-in encoder input channels and 100 kHz maximum encoder input frequency make it suitable for synchronized conveyor indexing, counting, and position tracking.
Supports high-speed pulse counting and motion-related coordination without a separate counter module.
RS-232C, RS-485, and USB communication ports allow straightforward connection to HMIs, drives, or supervisory devices in small OEM machines.
Enables simple field communication and commissioning in compact automation architectures.
