64-point sinking transistor output module, 12–24 VDC load range, 0.3 A/point, rack-mounted for CS1 PLC systems.
CS1W-OD261 is a CS1-series transistor output unit for Omron SYSMAC PLC systems. The manufacturer datasheet identifies it as a 64-point sinking output module with a rated load supply of 12 to 24 VDC and 0.3 A per output. It is designed for CS1 rack mounting and uses connector-based external wiring. The datasheet also shows 4.0 words of PLC memory usage and approximately 0.39 A current consumption, while the manual lists a maximum load current of 0.3 A/point, 1.6 A/common, and 6.4 A/unit, with 3.0 A inrush current per point.
| Parameter | Value |
|---|---|
| Output type | Transistor output unit |
| Output configuration | 64 outputs |
| Output mode | Sinking |
| Rated load voltage | 12 to 24 VDC |
| Operating load voltage range | 10.2 to 26.4 VDC |
| Maximum load current | 0.3 A/point |
| Maximum load current per common | 1.6 A/common |
| Maximum load current per unit | 6.4 A/unit |
| Maximum inrush current | 3.0 A/point, 10 ms max |
| Leakage current | max. 0.1 mA |
| Residual voltage | max. 1.5 V |
| Turn-on delay | max. 0.5 ms |
| Turn-off delay | max. 1.0 ms |
| Internal 5-V current consumption | max. 390 mA |
| PLC memory usage | 4 words |
| External connection | Two connectors for external wiring (soldered) |
| Insulation resistance | 20 MΩ between external terminals and GR terminal at 100 VDC |
| Dielectric strength | 1,000 VAC between external terminals and GR terminal for 1 minute at max. 10 mA leakage current |
Drives up to 64 DC solenoid coils in machine automation where many discrete outputs must be packed into a single PLC slot.
Reduces rack space and wiring complexity for dense valve manifolds and pneumatic control panels.
Controls numerous 24 VDC actuators, relays, and interface loads in sequential packaging or assembly machines requiring many synchronized discrete signals.
Provides enough channel count and current capability for compact sequencing without multiple smaller modules.
Interfaces PLC logic to interposing relays and pilot devices in industrial panels using 24 VDC control circuits with low leakage and fast switching.
Enables reliable PLC-to-field load interfacing while preserving fast response and manageable current per channel.
