Omron E52-P10AEY 2M Class B Pt100 sensor with SUS316 construction, three-conductor output and 2 m PFA lead.
The Omron E52-P10AEY 2M is a low-cost Pt100 resistance thermometer with a Class B element and three-conductor system. It uses SUS316 protective tubing and measures from 0°C to 250°C. The 2 m PFA-covered lead is specified for −50°C to 150°C; connect it to a compatible RTD input and confirm installation and process conditions.
Class B Pt100 sensor with SUS316 protective tubing and 2 m PFA-covered lead.
| Parameter | Value |
|---|---|
| Manufacturer | Omron |
| Product type | Low-cost platinum resistance thermometer |
| Element type | Pt100 |
| Conductor system | 3-conductor |
| Accuracy class | Class B |
| Temperature range | 0°C to 250°C |
| Protective tubing | SUS316 |
| Lead wire | 2 m PFA-covered wire; −50°C to 150°C |
| Physical Weight (kg) | Not stated in the checked manufacturer product data. |
| Dimensions L x W x H (cm) | Overall L × W × H not stated in the checked manufacturer product data. |
| Supply status | Unknown; exact model and specifications are confirmed, current supply status was not established. |
Engineering suggestions require suitability checks for your installation.
Connect a platinum resistance sensor to a compatible temperature controller for process feedback.
Wire all three conductors to the RTD input and select mounting and immersion depth to suit the process.
Measure process temperature where the probe material and operating range suit the installation.
Check chemical and mechanical compatibility of the SUS316 probe and keep lead temperature within −50°C to 150°C.
