3 MB CPU with EtherCAT/EtherNet/IP, database connectivity, 1 ms cycle time, DIN-rail mount, up to 64 EtherCAT nodes.
Sysmac NJ1 CPU module with database connectivity for machine automation. The NJ101-1020 integrates 3 MB program memory, built-in EtherCAT and EtherNet/IP, USB/Ethernet programming, and support for up to 64 EtherCAT nodes. It is intended for compact control applications requiring motion, sequence, and database communications in a DIN-rail mounted controller.
| Parameter | Value |
|---|---|
| Controller functionality | DB connection, motion control, sequence control |
| Program memory | 3 MB |
| Variables memory | 0.5 MB |
| Primary task cycle time | 1 ms |
| Max. number of synchronous axes | 2 |
| Max. number of axes (including virtual) | 6 |
| Communication ports | EtherCAT Master, EtherNet/IP, USB |
| Communication options | CAN, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485 |
| Max. number of remote I/O nodes | 64 |
| I/O system | CJ I/O Bus |
| Max. number of expansion units | 40 |
| Product height (unpacked) | 97.5 mm |
| Product width (unpacked) | 90 mm |
| Product depth (unpacked) | 90 mm |
| Product weight (unpacked) | 550 g |
| Mounting | DIN rail |
Use the controller to coordinate sequence logic, limited motion, and database connectivity in a compact packaging line that needs production traceability.
Combines PLC logic and SQL-style data exchange without needing a separate industrial PC.
Suitable for a two-axis indexing or positioning station where synchronized motion and EtherCAT device control are required.
Provides deterministic motion control for a small number of axes while keeping the control cabinet compact.
Fits machines that need a controller to collect I/O, exchange data over EtherNet/IP, and connect to upstream systems while remaining expandable.
Unifies machine control and network integration with support for up to 64 remote I/O nodes and 40 expansion units.
