3 MB CPU unit with EtherCAT/EtherNet/IP, 0 axes, 2,560-point I/O, 1 ms cycle, 90 mm cube footprint.
NJ-series CPU unit for simple machine automation with built-in EtherCAT Master and EtherNet/IP. The NJ101-9000 is a 3 MB program-memory controller with 0 motion axes, 2,560-point local I/O capacity, 40 total units on the system, and 1 ms primary task cycle time. Omron’s published general specifications list a 90 mm × 90 mm × 90 mm enclosure size, 550 g weight including the end cover, and 5 VDC 1.90 A current consumption including SD memory card and end cover.
| Parameter | Value |
|---|---|
| Program capacity | 3 MB |
| I/O capacity | 2,560 points local (8,960 with NX I/O) |
| Maximum number of units | 10 per CPU or expansion rack; 40 total per CPU |
| Total axes | 0 |
| Motion control network | EtherCAT |
| Communication ports | EtherCAT and EtherNet/IP built in |
| Programming connection | USB / Ethernet |
| Mounting | DIN Rail |
| Controller functionality | Sequence control |
| Primary task cycle time | 1 ms |
| Variables memory | 0.5 MB retained, 2 MB not retained |
| Enclosure | Mounted in a panel |
| Grounding method | Ground to less than 100 Ω |
| Dimensions (height × depth × width) | 90 mm × 90 mm × 90 mm |
| Weight | 550 g (including the end cover) |
| Current consumption | 5 VDC, 1.90 A (including SD Memory Card and End Cover) |
| Operating temperature | 0 to 55°C |
| Operating humidity | 10% to 90% (with no condensation) |
| Storage temperature | -20 to 75°C (excluding battery) |
| Altitude | 2,000 m or less |
| Pollution degree | 2 or less |
| Noise immunity | 2 kV on power supply line |
| Overvoltage category | Category II |
| EMC immunity level | Zone B |
| Vibration resistance | IEC 60068-2-6 compliant |
| Shock resistance | IEC 60068-2-27 compliant |
| Battery life | 5 years at 25°C |
| Battery model | CJ1W-BAT01 |
| Applicable standards | cULus, EU, UKCA, RCM, KC, NK, LR |
Controls a small assembly cell that needs deterministic sequence logic, local I/O, and industrial Ethernet connectivity in a compact 90 mm cube controller.
Replaces larger PLCs when only sequence control and moderate I/O count are required.
Coordinates a machine with both EtherCAT and EtherNet/IP devices, making it suitable for mixed-vendor field networks without adding a separate gateway controller.
Eliminates extra protocol bridging hardware for compact automation panels.
Fits OEM machine panels where enclosure volume is limited but a full-featured controller with SD backup, 1 ms tasking, and 550 g hardware mass is needed.
Provides deterministic control in tight control cabinets with limited space and thermal budget.
