16-axis robot-integrated controller with coordinated logic, motion, and up to 8 OMRON robots; panel-mounted NJ-series CPU.
Robot-integrated machine automation controller for coordinated logic, motion, and OMRON robot control in one CPU. The NJ501-R300 is listed by OMRON as a 16-axis integrated controller with support for up to 8 controllable OMRON robots and no database function. It is part of the NJ501-R robot integrated CPU family and is designed for panel mounting in industrial automation systems. OMRON technical literature confirms the shared NJ-series hardware platform, while the R300 variant is identified in the product datasheet and catalog listings.
| Parameter | Value |
|---|---|
| Maximum controlled axes | 16 axes |
| Maximum controllable OMRON robots | 8 max. |
| Database connection function | Not supported on NJ501-R300 |
| Mounting | Mounted in a panel |
| Dimensions (H × D × W) | 90 mm × 90 mm × 90 mm |
| Weight | 550 g (including the End Cover) |
| Current consumption | 5 VDC, 1.90 A (including SD Memory Card and End Cover) |
| Ambient operating temperature | 0 to 55°C |
| Ambient operating humidity | 10% to 90% (with no condensation) |
| Ambient storage temperature | -20 to 75°C (excluding battery) |
| Altitude | 2,000 m or less |
| Pollution degree | 2 or less |
| Noise immunity | 2 kV on power supply line |
| Overvoltage category | Category II |
| EMC immunity level | Zone B |
Coordinates up to 16 motion axes and multiple OMRON robots from a single CPU, reducing controller sprawl in compact assembly cells.
Eliminates the need for separate PLC, motion, and robot controllers in synchronized cells.
Suitable for pick-and-place lines where multiple robots and axes must be synchronized in a confined enclosure with standard industrial environmental limits.
Supports synchronized robot handling without requiring a database-enabled controller variant.
Useful for machines needing embedded kinematic sequencing and deterministic control in a 90 mm class controller footprint.
Provides integrated control in a small footprint, reducing cabinet space and wiring complexity.
