USD 21,382.94
64-axis robot-integrated CPU with 20 MB program memory, 8 OMRON robots max, panel-mount industrial controller.
Robot-integrated CPU unit for Omron Sysmac NJ-series control, combining logic, motion, OMRON robot control, and kinematics in a single controller. The NJ501-R500 supports up to 64 motion axes and up to 8 controlled OMRON robots, with 20 MB program capacity, 2 MB retained variable memory, and 4 MB non-retained variable memory. It is panel-mounted, designed for industrial control environments, and shares the NJ501-R family’s standard CPU form factor and width.
| Parameter | Value |
|---|---|
| Program capacity | 20 MB |
| Retained variable memory | 2 MB |
| Non-retained variable memory | 4 MB |
| Number of motion axes | 64 |
| Maximum number of controlled OMRON robots | 8 |
| Enclosure | Mounted in a panel |
| CPU unit width | 90 mm |
| Current consumption | 5 VDC, 1.90 A (including SD Memory Card and End Cover) |
| Ambient operating temperature | 0 to 55°C |
| Ambient operating humidity | 10% to 90% (with no condensation) |
| Ambient storage temperature | -20 to 75°C (excluding battery) |
| Altitude | 2,000 m or less |
| Pollution degree | 2 or less |
| Noise immunity | 2 kV on power supply line |
| Overvoltage category | Category II |
| Battery model | CJ1W-BAT01 |
| Battery life | 5 years at 25°C |
| Unit width in assembly | 90 mm |
Controls up to 8 OMRON robots from one CPU while coordinating 64 motion axes for synchronized pick, place, and transfer sequencing.
Eliminates separate robot and motion controllers, reducing synchronization latency and cabinet complexity.
Provides centralized logic and motion coordination for machine stations that need deterministic sequencing across many servo axes.
Solves coordination bottlenecks in multi-axis assembly systems by unifying logic and motion in one controller.
Fits existing control cabinets as a panel-mounted NJ-series CPU while adding robot integration and kinematics without splitting control across multiple platforms.
Simplifies retrofits where cabinet space, wiring, and controller interoperability are constrained.
