USD 1,183.95
DIN-rail CPU module with integrated EtherCAT, dual Ethernet, OPC UA, 5 MB program memory, and 1 ms cycle time.
NX102-1000 is an Omron NX1 machine automation controller CPU unit for Sysmac architectures, combining motion control, sequence control, OPC UA connectivity, and EtherCAT/EtherNet/IP communications. Official Omron sources identify it as a DIN-rail mounted CPU module with 5 MB program memory, 33.5 MB variable memory, 1 ms primary task cycle time, and integrated EtherCAT Master plus dual Ethernet ports. It supports up to 2 synchronous axes and 4 PTP axes, making it suitable for compact high-performance machine control applications.
| Parameter | Value |
|---|---|
| Program memory | 5 MB |
| Variable memory | 33.5 MB |
| Primary task cycle time | 1 ms |
| Communication ports | EtherCAT Master, EtherNet/IP, Ethernet TCP/IP |
| Motion control | Yes |
| OPC UA | Yes |
| Max. number of synchronous axes | 2 |
| Max. number of PTP axes | 4 |
| Max. number of axes (including virtual) | 15 |
| Max. number of remote I/O nodes | 64 |
| Max. number of expansion units | 32 |
| Mounting | DIN rail |
| Product height (unpacked) | 100 mm |
| Product width (unpacked) | 66 mm |
| Product depth (unpacked) | 100 mm |
| Product weight (unpacked) | 470 g |
Controls synchronized motion and sequencing for small packaging lines where precise coordination between a few axes is required.
Eliminates separate motion and logic controllers while keeping deterministic 1 ms task timing and EtherCAT synchronization.
Acts as the central controller for a machine that must exchange production data using OPC UA and Ethernet-based industrial networking.
Provides native OPC UA and dual Ethernet communications for integrated data exchange without extra gateway hardware.
Fits modular assembly or inspection cells using NX-series remote I/O and compact expansion architecture.
Supports high-density local and remote I/O expansion while keeping cabinet footprint low and wiring simple.
