USD 1,354.94
24 VDC machine automation CPU with 5 MB program memory, EtherCAT master, EtherNet/IP, OPC UA, and up to 4 synchronous axes.
NX102-1100 is an Omron NX1 machine automation controller CPU unit for Sysmac-based control, combining motion control, sequence control, OPC UA, and integrated EtherCAT/EtherNet/IP communications. Manufacturer and distributor listings identify it as a 24 VDC CPU unit with 5 MB program memory, support for 4 synchronous axes, 4 PTP axes, and up to 15 total axes including virtual axes. It is intended for panel-mounted industrial automation systems requiring deterministic control, coordinated motion, and networked I/O integration.
| Parameter | Value |
|---|---|
| Supply voltage | 24 VDC |
| Program memory | 5 MB |
| Retained variable memory | 1.5 MB |
| Non-retained variable memory | 32 MB |
| Maximum synchronous axes | 4 |
| Maximum PTP axes | 4 |
| Maximum axes including virtual axes | 15 |
| Primary task cycle time | 1 ms |
| Communication ports | EtherCAT Master, EtherNet/IP, Ethernet TCP/IP |
| Communication options | Serial RS-232C, Serial RS-422, Serial RS-485 |
| Max remote I/O nodes | 64 |
| Controller functionality | Motion control, OPC-UA, Position control, Sequence control |
| Mounting | Mounted in a panel |
| Ambient operating temperature | 0 to 55 °C |
| Ambient operating humidity | 10% to 95% (no condensation) |
| Ambient storage temperature | -25 to 70 °C (excluding battery) |
| Altitude | 2,000 m max. |
| Pollution degree | 2 or less |
| Noise immunity | 2 kV on power supply line |
| Overvoltage category | Category II |
| Vibration resistance | Conforms to IEC 60068-2-6 |
| Shock resistance | Conforms to IEC 60068-2-27 |
| Applicable standards | cULus, EU, UKCA, RCM, KC, NK, LR |
Use the controller to synchronize conveyors, sealers, and indexing stations with EtherCAT-based deterministic motion control and 4 synchronous axes.
Eliminates timing drift and coordination errors in multi-axis packaging machinery.
Coordinate multiple servo axes and discrete sequence logic for compact pick-and-place automation with up to 4 PTP axes and 15 total axes.
Provides precise, repeatable multi-axis positioning without external motion hardware.
Act as the central controller for a smart machine cell connecting local I/O and supervisory systems through EtherNet/IP and OPC UA.
Simplifies plant connectivity and data exchange while maintaining real-time control.
