USD 2,252.68
Database-ready PLC CPU with 5 MB program memory, EtherCAT, dual Ethernet, and up to 12 total axes.
NX102-1220 is an Omron NX-series database connection CPU unit for machine automation. Manufacturer documentation identifies it as a Sysmac NX1 modular CPU with 5 MB program memory, 32 MB non-retained variable memory, built-in EtherCAT, and two Ethernet ports supporting OPC UA and EtherNet/IP. Omron’s specification page lists support for up to 12 total axes, including 8 motion control axes and 4 single-axis position control axes, with a minimum cycle time of 1 ms. Distributor listings confirm it as an Omron automation controller module for DIN-rail mounting.
| Parameter | Value |
|---|---|
| Program capacity | 5 MB |
| Memory capacity for variables (retained during power interruption) | 1.5 MB |
| Memory capacity for variables (not retained during power interruption) | 32 MB |
| Maximum number of used real axes | 12 |
| Motion control axes | 8 |
| Single-axis position control axes | 4 |
| Motion control network | EtherCAT |
| Communication ports | EtherCAT and 2x EtherNet/IP built in |
| Programming connection | Ethernet |
| Minimum cycle time | 1 ms |
| Mounting | DIN Rail |
| Special function | NX Local Bus |
The 1 ms minimum cycle time, EtherCAT motion network, and support for 8 motion axes make it well suited for coordinated packaging machinery with synchronized conveyors, cutters, and sealers.
Eliminates timing drift and coordination errors in high-speed multi-axis packaging systems.
The database connection CPU architecture and dual Ethernet ports support machine data capture, line identification, and direct integration with plant databases for serialization or quality tracking.
Reduces integration complexity when the controller must both run the machine and exchange production data with higher-level systems.
With DIN rail mounting, local NX bus support, and up to 12 total axes, the unit is appropriate for compact automation skids that need a centralized controller for servo positioning and station sequencing.
Consolidates motion and sequencing control into a single compact controller for smaller machine footprints.
