USD 970.20
NX-series CPU with 5 MB program memory, integrated EtherCAT, dual Ethernet, and 1 ms minimum cycle time.
NX102-9000 is an Omron NX-series machine automation CPU unit with 5 MB program capacity, 32 MB non-retained memory, integrated EtherCAT, and dual Ethernet communications. Manufacturer and distributor sources identify it as a DIN-rail mounted NX1 CPU module for Sysmac automation, supporting up to 4 total point-to-point axes, 1024 local I/O points, and 1 ms minimum cycle time. Omron’s product page and catalog identify the exact part as a standard-stock NX1 CPU unit in the NX102 family.
| Parameter | Value |
|---|---|
| Program capacity | 5 MB |
| Memory capacity for variables | 32 MB non-retained |
| Built-in motion network | EtherCAT |
| Communication ports | 2 Ethernet ports |
| Supported communications | OPC UA and EtherNet/IP |
| Total axes / point-to-point / coordinated axes | 4 / 4 / 0 |
| Minimum cycle time | 1 ms |
| Local I/O capacity | 1024 points local |
| Maximum local NX units | 32 NX units local |
| Mounting | DIN rail |
| Programming languages | Ladder / Structured Text / Function Block |
| Standards and approvals | UL, CSA, CE, NK listed on Omron regional product pages |
The 4 total point-to-point axes and EtherCAT network make it suitable for compact motion-controlled equipment such as indexing machines or small assembly cells.
Coordinates deterministic motion control without requiring a separate motion controller.
The 1024 local I/O points and 32 local NX units support dense sensor/actuator wiring for packaging or material-handling skids.
Handles large local I/O count in a compact DIN-rail controller architecture.
Dual Ethernet ports plus OPC UA and EtherNet/IP support make it well suited to machines that must exchange data with SCADA, MES, or plant networks.
Bridges machine control and higher-level industrial communication without extra gateways.
