Omron NX102-9020 PLC CPU Module

Technical Overview

NX1 database-connection CPU unit with built-in EtherCAT master, EtherNet/IP, and Ethernet TCP/IP communication. Designed for sequence control, position control, and industrial data connectivity, this unit provides 5 MB program memory, 33.5 MB variable memory, and support for up to 64 remote I/O nodes and 32 expansion units. Official Omron specifications also list 4 PTP axes, 1 ms primary task cycle time, DIN-rail mounting, and compact controller dimensions.

Key Features

Database connection, OPC-UA, position control, and sequence control
Built-in EtherCAT Master and EtherNet/IP communication
4 PTP axes and 4 total axes support
5 MB program memory and 33.5 MB variable memory
1 ms primary task cycle time
Up to 64 remote I/O nodes
Up to 32 expansion units
DIN rail mounting
Serial communication options: RS-232C, RS-422, RS-485

Technical Specification Matrix

Parameter	Value
Controller functionality	DB connection, OPC-UA, Position control, Sequence control
Max. number of synchronous axes	0
Max. number of PTP axes	4
Max. number of axes (incl. virtual)	4
Primary task cycle time	1 ms
Program memory	5 MB
Variables memory	33.5 MB
Communication port(s)	EtherCAT Master, EtherNet/IP, Ethernet TCP/IP
Communication option(s)	Serial RS-232C, Serial RS-422, Serial RS-485
Max. number of remote I/O nodes	64
I/O system	NX I/O Bus
Max. number of expansion units	32
Product Height (unpacked)	100 mm
Product Width (unpacked)	66 mm
Product Depth (unpacked)	100 mm
Product Weight (unpacked)	470 g

Industrial Applications

1. Compact machine sequencing controller

Ideal for compact automated machines that need deterministic sequence control with a 1 ms task cycle and built-in industrial networking.

Problem Solved

Provides a small-form-factor PLC CPU for machines that need fast scan performance and integrated connectivity without a separate controller stack.

1 ms cycle timesequence controlEtherNet/IPDIN railcompact PLC

2. Small motion platform with point-to-point axes

Fits machines requiring up to 4 PTP axes, such as indexing, pick-and-place, or light servo positioning systems.

Problem Solved

Eliminates the need for a separate motion controller when only a few point-to-point axes are required.

4 PTP axesposition controlEtherCAT Mastermotion controlindustrial automation

3. Edge-connected manufacturing cell with data logging

Suitable for cells that must exchange production data with higher-level systems through OPC-UA, SQL-oriented database connectivity, or TCP/IP.

Problem Solved

Solves the integration gap between shop-floor control and IT-level data exchange in a single controller.

DB connectionOPC-UAEtherNet/IPEthernet TCP/IPindustrial data connectivity
