USD 13,046.85
80 MB Sysmac CPU with 128 motion axes, database connectivity, OPC UA, built-in EtherCAT, and dual EtherNet/IP ports.
NX701-1620 is an Omron NX-series database-connection CPU unit for the Sysmac platform. Manufacturer documentation identifies it as a CPU unit with 80 MB program capacity, 128 motion axes, OPC UA support, built-in EtherCAT, and two built-in EtherNet/IP ports. The official datasheet lists the NX701-1620 within the NX701 database connection CPU family and shows the unit is panel-mounted, with industrial environmental ratings and 24 VDC control-system current consumption stated for the family table. Exact physical size and weight are published in the NX/NJ series datasheet for NX701 CPU units: 100 mm × 100 mm × 132 mm and 880 g including end cover.
| Parameter | Value |
|---|---|
| Program capacity | 80 MB |
| Motion axes | 128 |
| Database connection | Supported |
| OPC UA | Supported |
| Built-in motion network | EtherCAT |
| Built-in Ethernet/IP ports | 2 |
| Programming connection | USB / Ethernet |
| Mounting | DIN rail |
| Enclosure | Mounted in a panel |
| Operating temperature | 0 to 55°C |
| Operating humidity | 10% to 95% (with no condensation) |
| Storage temperature | -25 to 70°C |
| Altitude | 2,000 m or less |
| Pollution degree | 2 or less |
| Noise immunity | 2 kV on power supply line |
| Overvoltage category | Category II |
| Dimensions (H × D × W) | 100 mm × 100 mm × 132 mm |
| Weight | 880 g (including the End Cover) |
| Current consumption | 5 VDC, 1.90 A (including SD Memory Card and End Cover) |
| Power consumption | 40 W (including SD Memory Card and End Cover) |
Controls a large packaging or case-packing line where multiple servo axes must be synchronized through EtherCAT while line data is exchanged with higher-level systems via OPC UA.
Eliminates separate motion and data gateways by combining 128-axis control, OPC UA, and industrial networking in one CPU.
Runs a production cell that needs direct connection to manufacturing databases for recipe, genealogy, or lot-tracking workflows without an external PC controller.
Provides embedded database connectivity and machine control in one unit, reducing integration complexity and external compute dependencies.
Acts as the central controller in machines requiring simultaneous EtherCAT motion control and dual EtherNet/IP communication to SCADA, MES, or remote I/O networks.
Consolidates motion and plant networking into one controller, minimizing cabinet space and network bridging hardware.
