USD 14,543.07
NX-series AI CPU unit with 80 MB program capacity, 256-axis motion control, and 24 VDC panel-mounted industrial automation architecture.
NX701-Z700 is an NX-series CPU unit with AI function for large-scale machine automation. The official OMRON ordering data shows 80 MB program capacity, 4 MB retained variable memory, 256 MB non-retained variable memory, and support for 256 motion axes. It is a panel-mounted controller with 24 VDC supply architecture via the NX-series supply unit, intended for fast, highly accurate control within the Sysmac platform.
| Parameter | Value |
|---|---|
| Program capacity | 80 MB |
| Memory capacity for variables (retained during power interruption) | 4 MB |
| Memory capacity for variables (not retained during power interruption) | 256 MB |
| Number of motion axes | 256 |
| Power consumption | 40 W (including SD Memory Card and End Cover) |
| Enclosure | Mounted in a panel |
| Grounding method | Ground to less than 100 Ω |
| Dimensions (height × depth × width) | 100 mm × 100 mm × 132 mm |
| Weight | 880 g (including the End Cover) |
| Ambient operating temperature | 0 to 55°C |
| Ambient operating humidity | 10% to 95% (with no condensation) |
| Ambient storage temperature | -25 to 70°C (excluding battery and fan unit) |
| Altitude | 2,000 m or less |
| Pollution degree | 2 or less |
| Noise immunity | 2 kV on power supply line |
| Overvoltage category | Category II |
| EMC immunity level | Zone B |
| Vibration resistance | Conforms to IEC 60068-2-6 |
| Shock resistance | Conforms to IEC 60068-2-27 |
| Battery life | 2.5 years at 25°C, Power ON time rate 0% (power OFF) |
| Battery model | CJ1W-BAT01 |
| Applicable standards | cULus, EU, UKCA, RCM, KC, NK, LR |
Suitable for synchronized packaging lines that require coordinated multi-axis motion and deterministic control across numerous servo axes.
Eliminates controller bottlenecks in high-axis-count machines by supporting up to 256 motion axes.
Fits complex assembly cells where multiple stations, conveyors, and actuators must be controlled from one central NX-series controller.
Consolidates distributed machine logic into one panel-mounted controller with large program and variable memory.
Works in precision test stands and indexing machines that need fast control, compact enclosure mounting, and stable industrial environmental tolerance.
Supports compact integration while maintaining industrial resilience to vibration, shock, and temperature variation.
