1. Interfacing 230V AC Machine Signals to Low-Voltage DC Control Systems
In industrial machinery, safety and control systems often operate at low DC voltages (e.g., 24 V DC), while sensors or actuators providing feedback may operate on 230 V AC. This solid-state relay acts as a robust interface, converting a 230 V AC input signal into a galvanically isolated DC output suitable for PLCs or other low-voltage control circuits. The 2.5 kV AC isolation protects sensitive electronics, and the compact 6.2mm width allows for dense panel integration.
Problem SolvedSafely and reliably interfaces high-voltage AC feedback signals from machinery (e.g., motor status, limit switches) with sensitive low-voltage DC control logic, preventing damage due to voltage mismatches and providing electrical isolation for safety.
PLC interfaceAC/DC conversiongalvanic isolationindustrial controlmachine safety230V AC24V DC
2. Switching Low-Power DC Loads from 230V AC Building Management Systems
In modern building automation, central management systems often use 230V AC for control signals. This relay can take a 230V AC command (e.g., 'turn on light', 'activate fan') and safely switch a low-power DC load (e.g., 24 V DC LED driver, small DC fan motor, or a signal to a DC-controlled damper) with its 3-48V DC/100mA output. Its compact 6.2mm size allows for dense installations within control panels.
Problem SolvedEnables the integration of 230V AC building control signals with low-voltage DC loads or control circuits, providing reliable, wear-free switching for applications like intelligent lighting, fan control, or damper actuation, while maintaining electrical separation.
Building automationHVAC controllighting control230V AC input24V DC outputlow-power switchingelectrical isolation
3. Process Control Signal Conditioning in Demanding Environments
In process industries, control panels need to accept signals from various field devices. If a field device provides a 230V AC status signal (e.g., pump running indication) but the central DCS/PLC requires a 24V DC input, this solid-state relay provides the necessary voltage conversion and critical 2.5 kV AC isolation. Its operating temperature range of -20 °C to 60 °C makes it suitable for typical industrial control cabinet environments.
Problem SolvedProvides reliable and isolated conversion of 230V AC process signals to 24V DC for PLC/DCS systems, ensuring signal integrity, protecting sensitive control electronics from voltage surges, and allowing operation in standard industrial temperature ranges.
Process automationsignal conditioningelectrical isolationDCS/PLC input230V AC24V DCindustrial environment
