1. Control Panel Wiring for Common Potentials
In industrial control panels, multiple devices often require connection to a common potential (e.g., ground, 24VDC). This insertion bridge simplifies wiring by allowing quick and secure bridging of 10 adjacent terminal blocks with a 6.2 mm pitch, reducing wiring complexity and installation time.
Problem SolvedEliminates the need for individual jumpers or intricate wiring for common potential distribution across multiple terminals, improving efficiency and reliability.
Control panelcommon potentialterminal blockwiring simplificationelectrical distribution
2. Signal Distribution in PLC I/O Systems
For programmable logic controller (PLC) input/output systems where a group of sensors or actuators share a common signal or power line, the EB 10- 6 insertion bridge can link up to 10 I/O terminals. Its precise 6.2 mm pitch ensures compatibility with standard industrial terminal blocks, facilitating organized and robust signal distribution.
Problem SolvedStreamlines the connection of shared signals to multiple PLC I/O points, preventing wiring errors and enhancing system maintainability.
PLC I/Osignal distributioncommon signalterminal block bridgingindustrial automation
3. Power Bus Connection in Industrial Enclosures
Within larger industrial enclosures, establishing a power bus for auxiliary components (e.g., relays, indicators) across a section of terminal blocks is critical. This 10-position insertion bridge with a 6.2 mm pitch provides a reliable, direct electrical link between terminals, ensuring consistent power delivery without complex cabling.
Problem SolvedCreates a compact and secure power bus for distributing power to multiple loads from a single source within an industrial enclosure, optimizing space and reducing connection points.
Power busindustrial enclosurepower distributionauxiliary componentselectrical linking
