$ 265.42
Reliable Phoenix Contact PSR-SCP-24DC/ESD/4X1/30 safety relay for emergency stop, safety doors, and light grids. Compact, certified, and easy to install.
The Phoenix Contact PSR-SCP-24DC/ESD/4X1/30 safety relay is a compact and dependable solution for safeguarding emergency stop functions, safety doors, and light curtains in industrial settings. Built to comply with SIL 3, Category 4, and Performance Level e safety standards, it provides maximum protection for operators and equipment. With selectable dropout delays between 0.1 and 30 seconds and the choice of manual or automatic reset, the relay adapts to varied safety requirements. Designed with force-guided contacts, durable housing, and reliable performance, it is well suited for high-demand applications where safety and uninterrupted machine operation are critical.
The Phoenix Contact PSR-SCP-24DC/ESD/4X1/30 combines safety, flexibility, and ease of integration into one device. Supporting both single- and dual-channel control, it can be configured for use in emergency stop circuits, monitored access doors, or optical light barriers. Its pluggable screw terminals make installation straightforward, while built-in protective mechanisms prevent unauthorized adjustment of delay times. The slim 22.5 mm housing saves valuable control cabinet space and simplifies wiring in complex safety systems. With international approvals and certifications, it provides engineers with confidence that the system meets global safety standards, ensuring uptime while maintaining a secure environment for people and machines.
The PSR-SCP-24DC/ESD/4X1/30 is more than just a safety relay—it’s a guardian for modern automation systems. Its slim design, adjustable delay times, and global safety certifications make it the trusted choice for engineers who need both flexibility and compliance. It ensures protection without compromising efficiency, delivering reliability where every second and every safeguard matters.
Industrial machines pose serious risks without proper safety measures. The PSR-SCP-24DC/ESD/4X1/30 eliminates uncertainty by ensuring emergency stops, safety doors, and light grids are monitored with absolute reliability. It solves the challenge of balancing productivity with safety, reducing downtime while keeping operators protected. In short, it transforms complex safety demands into simple, dependable control.
| Feature | Details | Benefit |
|---|---|---|
| Supply Voltage | 24 V DC | Standard industrial voltage for easy integration. |
| Safety Standards | SIL 3, Cat. 4, PL e | Certified safety compliance for critical industrial applications. |
| Activation Modes | Manual or Automatic | Flexible control for diverse safety architectures. |
| Delay Time Range | Adjustable 0.1 – 30 s | Provides controlled shutdowns and prevents nuisance trips. |
| Outputs | 4 enabling current paths, up to 6 A | Handles multiple circuits with strong switching capability. |
| Connection Type | Plug-in screw terminals | Simplifies wiring and speeds up installation. |
| Housing Width | 22.5 mm | Slim profile saves valuable DIN rail space. |
| Protection Level | IP20 (device), IP54 (installation location) | Reliable operation under industrial conditions. |
| Service Life | Up to 10⁷ mechanical cycles | Long-lasting durability reduces replacement costs. |
| Applications | Emergency stop, safety doors, light grids | Broad usage across machine and plant safety systems. |
Download PSR-SCP-24DC/ESD/4X1/30 2981800 Datasheet
In heavy metalworking environments, press brakes pose significant risks due to moving rams. By connecting both a light curtain and an emergency stop into the safety relay, the system halts instantly when an operator’s hand enters the danger zone or when the stop button is pressed. The adjustable delay prevents false triggers while maintaining strict safety. Its dual-channel monitoring provides redundancy, ensuring that even if one input fails, protection remains active. This integration not only protects workers but also keeps production efficient, as the relay allows quick reset and reliable restart once conditions are safe.
High-speed packaging systems often include robotic arms and palletisers that need controlled access. The safety relay monitors each door so that when an access point opens, all motion is immediately disabled. Depending on requirements, the relay can be set for manual or automatic reset, allowing tailored control for hygiene or operational needs. Its pluggable terminal design reduces wiring complexity, making replacement or maintenance faster. Compact housing ensures minimal space consumption in cabinets that already hold multiple controllers. By combining certified safety levels with simple operation, it guarantees both worker protection and continuous line productivity.
Automotive production uses long conveyor lines to transport vehicle bodies through paint booths and curing zones. During cleaning or maintenance, access gates must be monitored so machinery powers down immediately. The safety relay ensures motors and hazardous components stop as soon as a door opens. Adjustable delay functions provide time for fans or heaters to shut down in a controlled manner, protecting sensitive equipment. Its slim design helps in already crowded control cabinets, while long mechanical service life supports frequent use without degradation. This solution enhances worker safety while preserving critical uptime in demanding automotive environments.
CNC machining centers require layered safety because operators interact closely with cutting tools. A safety relay supervises both enclosure doors and emergency stop circuits, cutting power instantly if either is triggered. Force-guided contacts and fault detection ensure wiring issues or stuck relays are recognized, maintaining system integrity. The adjustable dropout time supports rapid machine stops, critical when handling rotating spindles at high speeds. This arrangement balances worker protection with production efficiency, allowing quick resets once safe conditions return. It is especially valuable in industries such as aerospace or precision mold making, where reliability and accuracy are essential.
| Category | Model / Description | Part Number | Benefits |
|---|---|---|---|
| Accessory – Crimping Tool | CRIMPFOX 6 Crimping Pliers | 1212034 | Ensures secure wire terminations for ferrules, essential for reliable relay connections. |
| Accessory – Protective Label Set | PSR-ESD-300 Protective Labels | — | Prevents tampering with preset time settings, increasing safety and compliance. |
| Accessory – Electronic Protection | PSR-ESD-30 Electronic Guard | — | Provides electronic safeguards against manipulation of delay times. |
| Related Relay – Safety Expansion Module | PSR-SCP-24DC/ESD/2X1 | — | Expansion option for higher contact requirements in complex safety systems. |
| Related Relay – Compact Safety Relay | PSRclassic Series (various models) | — | Offers variations for emergency stop and safety door monitoring in smaller applications. |
| Mounting / Cabling | DIN Rail (Standard 35 mm) | — | Enables secure and quick mounting of the PSR safety relay. |
