$ 201.94
Enhance machine safety with Phoenix Contact PSR-SPP-24DC/SIM4. Compact interface module with LED status, diagnostics, and reliable safety compliance.
The Phoenix Contact PSR-SPP-24DC/SIM4 interface module is a compact and reliable solution for connecting multiple safety switches or sensors to a PSR safety relay. It supports both normally closed and normally open contacts, allowing flexible integration into industrial safety systems. Built with pluggable Push-in terminals, it reduces wiring effort and speeds up installation. The module meets high safety requirements, supporting applications up to Category 3/PL d and SIL 2 when used with the appropriate master relay. With status LEDs for each channel and diagnostic outputs for PLC evaluation, it ensures straightforward monitoring and enhanced operational safety.
The PSR-SPP-24DC/SIM4 interface module offers four independent two-channel inputs, making it suitable for monitoring multiple safety devices such as emergency stop buttons, guard doors, or light curtains. Compact in design, it optimizes cabinet space while maintaining strong performance. The built-in LED indicators help technicians quickly identify sensor states, reducing downtime during troubleshooting. Its diagnostic outputs provide valuable system feedback to higher-level controllers, improving overall process transparency. With robust construction, compliance to industrial safety standards, and easy installation, this module helps users achieve safer, more efficient production lines while lowering system complexity and maintenance costs.
Why Phoenix Contact PSR-SPP-24DC/SIM4?
The PSR-SPP-24DC/SIM4 is chosen for its ability to simplify complex safety wiring while ensuring compliance with international safety standards. With compact design, diagnostic outputs, and clear LED indicators, it delivers reliability and efficiency in monitoring multiple safety devices. It’s a smart choice for industries that demand both safety and streamlined installation.
What problem does it solve?
This interface module solves the challenge of connecting and managing several safety switches in one streamlined system. It eliminates wiring clutter, reduces installation errors, and provides clear diagnostics to prevent downtime. By ensuring consistent monitoring of safety functions, it gives engineers peace of mind while keeping production lines running smoothly and safely.
| Feature | Details | Benefit |
|---|---|---|
| Inputs | 4 two-channel N/O or N/C sensor connections | Flexible integration for multiple safety devices |
| Diagnostic Outputs | 4 PLC outputs | Provides real-time status feedback to controllers |
| Status Indicators | 4 LEDs (green) | Easy visual monitoring of connected sensors |
| Rated Input Voltage | 24 V DC (from PSR) | Stable operation in industrial automation systems |
| Safety Standards | Up to Cat. 3 / PL d (EN ISO 13849-1), SIL 2 (IEC 61508) | High-level compliance ensures functional safety |
| Connection Type | Push-in terminals, pluggable | Faster, tool-free wiring and reliable connections |
| Housing Width | 22.5 mm | Space-saving installation in control cabinets |
| Ambient Temperature | -20 °C … +55 °C (operation) | Reliable performance in demanding environments |
| Protection Degree | IP20 | Suitable for protected control cabinet use |
| Approvals | cULus Listed | Certified safety for international applications |
Download PSR-SPP-24DC/SIM4 2981949 Datasheet
| Commercial Data | Details |
|---|---|
| GTIN Number | 4046356325998 |
| Traffic / Tariff Number | 85364190 |
| Weight (Net / With Packaging) | 99.99 g / 175 g |
| Country of Origin | Germany |
In modern manufacturing cells, operators often work near CNC machines and automated equipment with multiple access doors. The PSR-SPP-24DC/SIM4 enables several door switches to be connected to a single safety relay. Each input channel has a clear LED indicator, making it simple to locate which guard is open or malfunctioning. The compact housing saves control cabinet space, while Push-in terminals reduce wiring errors during installation. By consolidating safety circuits in this way, manufacturers ensure rapid machine shutdown in unsafe situations while maintaining efficient operations.
High-speed packaging lines rely on safety interlocks to protect workers around conveyors, sealing machines, and robotic arms. The PSR-SPP-24DC/SIM4 provides a central interface to manage multiple interlocks at once. Diagnostic outputs allow controllers to track each switch’s condition, helping prevent unexpected downtime. Operators can see instantly which panel has been opened thanks to status LEDs. With safety compliance up to Cat. 3 / PL d, it creates a dependable safeguard for complex packaging systems. This balance of protection and system transparency improves both worker safety and production reliability.
Robotic cells in automotive assembly plants use a combination of light curtains, guard doors, and emergency stops to protect personnel. The PSR-SPP-24DC/SIM4 brings together up to four two-channel devices in one module. Flexible compatibility with both normally open and normally closed contacts makes it suitable for mixed sensor types. The integrated diagnostic outputs provide feedback to higher-level systems, giving maintenance teams insight into sensor health before problems escalate. With LED signaling for each input, faults can be pinpointed quickly, reducing downtime and keeping assembly lines running safely and efficiently.
Food processing plants require reliable safety systems on doors and covers surrounding cutting, filling, or packaging machinery. The PSR-SPP-24DC/SIM4 handles multiple interlocks in a single unit, reducing wiring complexity in areas where frequent cleaning and maintenance occur. Its wide temperature range allows use near cold storage zones without compromising performance. When an access point is opened, the connected relay immediately shuts down the equipment, ensuring operator safety. Status signals and diagnostic feedback help maintenance teams identify the specific interlock engaged, minimizing production delays and supporting strict hygiene and safety protocols.
| Category | Model | Part Number | Description | Benefit |
|---|---|---|---|---|
| DIN Rail Bus Connector | PSR-TBUS | 2890425 | Connector for safety switching devices, enabling supply, control, and monitoring. | Simplifies installation by providing a shared bus connection. |
| DIN Rail Blind Plug | PSR-TBUS-TP | 2981716 | Blind plug for unused sections of the PSR-TBUS rail system. | Ensures safe termination and protection of open connectors. |
| DIN Rail Bus Connector (1 pc) | PSR-TBUS | 1326060 | Single-piece connector for PSR modular safety devices. | Flexible option for small system expansions. |
| Crimping Tool | CRIMPFOX 6 | 1212034 | Crimping pliers for ferrules 0.25 mm²–6.0 mm², lateral entry. | Guarantees secure conductor connections with ferrules. |
| Safety Relay Master Module | PSR-SDC4 | — | Master relay unit required for operation with the SIM4. | Provides the safety logic for connected switches. |
| Extension Modules | PSR-URD3 / PSR-URM4 | — | Contact extension and monitoring modules compatible with SIM4. | Expand relay outputs or monitoring functions as needed. |
