SICK 2027721 BEF-AH-DME DME5000 Alignment Bracket

USD 124.28

Stainless-steel 1.4541 alignment unit for DME5000, with mounting hardware, slotted angular adjustment and an additional base-plate mounting kit required.

SKU SICK-2027721 Category
SICK Mounting Systems

SICK BEF-AH-DME DME5000 Alignment Bracket

BrandSICK
Model IdentifierBEF-AH-DME
Official Part Number2027721

Technical Overview

The SICK BEF-AH-DME is a stainless-steel 1.4541 alignment unit for DME5000 distance sensors. Mounting hardware is included, while an additional base-plate mounting kit is required. The three curved fixing slots provide the illustrated ±12.5° angular span around the R74 adjustment geometry.

Stainless-steel alignment unit for DME5000 with mounting hardware, curved fixing slots and an additional base-plate mounting kit requirement.

Key Features

  • Alignment mounting accessory for DME5000
  • Stainless-steel 1.4541 construction
  • Mounting hardware included
  • Additional base-plate mounting kit required
  • Three curved fixing slots
  • Illustrated fixing-slot angular span ±12.5°
  • R74 mm slot geometry
  • Adjustment aid identified in the manufacturer drawing
  • 163.4 mm span shown in the bracket drawing

Align a DME5000 sensor with a stainless-steel slotted mounting unit, using the included hardware and the separately required base-plate mounting kit.

Technical Specification Matrix

ParameterValue
Accessory groupMounting systems
Accessory familyBrackets
Mounting typeAlignment unit
CompatibilityDME5000
MaterialStainless steel, 1.4541
Items suppliedMounting hardware
Additional mounting requirementBase-plate mounting kit required
Fixing-slot arrangementThree curved slots; illustrated angular span ±12.5°
Drawing radiusR74 mm
Drawing span163.4 mm
Drawing reference height26 mm
Adjustment aidIdentified in manufacturer drawing
