1. Confirming a component at a short-range assembly point
An assembly station can present an opaque component within the adjusted sensing zone and read the PNP light-switching event. The axial M18 mounting and local potentiometer support alignment beside the fixture. Commissioning checks actual target remission and distance against the appropriate range, while electrical loading follows the supply and ambient-temperature derating conditions.
Problem Solved
A reflected-light event helps external assembly logic confirm component presentation from one mounting side, using the installed target surface and adjusted sensing distance as its detection basis.
Component presentation
Axial M18
PNP event
2. Counting separated objects along a guided feed
A guided feed can pass separated opaque objects across the sensing point and send PNP transitions to an external counter. The 500 Hz rating and response below 1,000 µs establish the timing basis. Setup checks target coverage of the light spot, actual remission, travel speed and spacing so each object produces a distinct event.
Problem Solved
Distinct reflected-light transitions give external counting logic passage events for separated objects, helping track feed quantity at a fixed sensing point without a separate receiver.
Object count
500 Hz
Reflected-light passage
3. Identifying an interrupted material-presence condition
A material-handling station can aim the sensor at an opaque strip or sheet that normally occupies a defined location. External logic observes loss of the PNP light-switching condition when a break or exhausted feed removes the material. Commissioning checks remission, surrounding surfaces and adjusted range so the material-present and material-absent states remain distinguishable.
Problem Solved
Loss of the established reflected-light condition helps external feed monitoring recognize missing material, allowing its process sequence to respond before continuing with an empty presentation point.
Material presence
Feed interruption
Light switching
