1. Confirming a metal slide at its end position
A guided slide can present a metal reference tab beside the flush sensor face at its expected end position. External sequencing reads the NPN normally-open condition after movement settles. Setup establishes the working gap against the 2.43 mm assured range and verifies target material and the metal clearances around the installed sensor.
Problem Solved
A repeatable metal-target condition gives external sequencing an end-position reference, helping distinguish slide arrival from withdrawal before the next ordinary process step.
Slide position
Flush sensing
NPN NO
2. Counting separated metal carriers
A transfer path can pass separated metal carriers across the sensing face and connect the NPN output to an external counter. The 2,000 Hz device rating establishes the sensor timing basis. Commissioning checks carrier size, material, speed and separation so each passage produces a distinct event within the sensor and receiving-input timing limits.
Problem Solved
Distinct inductive transitions let external counting logic track carrier passages at a fixed transfer point, helping compare delivered quantity with the expected production count.
Carrier count
2,000 Hz
Metal passage
3. Monitoring return timing of a cyclic linkage
A cyclic linkage can move a metal return flag past the flush sensing face during each ordinary stroke. External monitoring compares intervals between NPN events and identifies a missing or late return. Setup fixes the sensing position, checks the surrounding metal clearances and accounts for target-material reduction when establishing a repeatable working gap.
Problem Solved
A recurring metal-reference event helps external monitoring distinguish an ordinary linkage cycle from a delayed or interrupted return at a defined sensing position.
Return timing
Metal reference
Cyclic linkage
