1. Confirming a cylinder at its transfer position
A transfer cylinder can use the C-slot sensor at a selected stroke position so that its piston magnet operates the NPN normally-open signal. External sequencing logic reads that condition before requesting the next handling step. Setup adjusts and fixes the sensor position, checking the actual cylinder magnet, typical 4 mm overrun distance and external input loading against the 100 mA current limit.
Problem Solved
A piston-position reference helps external transfer logic recognize the selected cylinder position and coordinate the following handling operation without measuring the full stroke continuously.
Cylinder sequence
C-slot mounting
NPN signal
2. Timing cylinder arrival after an actuation command
A pneumatic station can start an external timer when it commands a cylinder movement and stop that timer when the NPN sensor reports arrival at the selected position. The C-slot mounting and normally-open signal establish the arrival reference. Commissioning checks actual piston-magnet behavior, travel direction and the 1,000 Hz specification against the station timing requirements.
Problem Solved
An arrival event gives external timing logic a repeatable endpoint for comparing command-to-arrival duration, helping identify a cylinder movement that takes longer than the configured process window.
Arrival timing
External timer
Position event
3. Counting repeated cylinder cycles for maintenance records
A machine can count NPN transitions at a selected cylinder position in an external maintenance counter. The sensor supplies a normally-open event as the piston magnet passes its installed C-slot location. The counter validates the expected movement sequence to avoid counting repeated transitions as separate cycles, and setup respects the 1,000 Hz specification and 100 mA current limit.
Problem Solved
Position events let external maintenance logic accumulate cylinder-cycle records, providing a usage reference for planned service while leaving counting and record storage in the controller.
Cycle counter
Maintenance record
External evaluation
