P55 is a round screw-on standard reflector in PMMA/ABS, with 48 mm reflective width across flats, 74 mm mounting-hole spacing and −20 to +65 °C operation.
The SICK P55 is a round standard reflector accessory with screw-on mounting and PMMA/ABS construction. Its reflective area is specified as 48 mm across flats, and the drawing provides two Ø4.5 mm mounting holes at 74 mm spacing. The operating temperature range is −20 to +65 °C.
Round screw-on PMMA/ABS standard reflector with 48 mm reflective width across flats, two Ø4.5 mm mounting holes and −20 to +65 °C operation.
Secure a PMMA/ABS standard reflector through two fixing holes, using the specified 74 mm hole spacing and 48 mm reflective width across flats.
| Parameter | Value |
|---|---|
| Product type | Standard reflector accessory |
| Design | Round; screw connection |
| Material | PMMA/ABS |
| Reflective area | 48 mm across flats; manufacturer catalog uses WS, wrench size |
| Mounting | Screw-on; two holes |
| Mounting-hole diameter | 4.5 mm |
| Mounting-hole spacing | 74 mm |
| Mounting-tab height | 86 mm; partial mechanical size |
| Depth in drawing | 9 mm; partial mechanical size |
| Operating temperature | −20 to +65 °C |
| RoHS manufacturer declaration | Listed by manufacturer |
