SICK 1000252 SST DO 80-090 90 mm Reflector Dust Protection Tube

USD 204.10

Anodized aluminum dust protection tube with 90 mm length, 80 mm outer diameter and 50 mm opening, for specified SICK reflectors including PL53A and OP61.

SKU SICK-1000252 Category
SICK Reflectors And Optics

SICK SST DO 80-090 90 mm Reflector Dust Protection Tube

BrandSICK
Model IdentifierSST DO 80-090
Official Part Number1000252

Technical Overview

The SICK SST DO 80-090 is an anodized aluminum dust protection tube for FLV-PL50, PL53A, SW50, OP60(-20), OP61 and SLV-PL50 reflectors. The passive optical accessory has a 90 mm length, 80 mm outer diameter and 50 mm clear opening.

Anodized aluminum reflector dust protection tube, 90 mm long with 80 mm outer diameter and 50 mm clear opening.

Key Features

  • Passive dust protection tube for compatible reflectors
  • Manufacturer accessory group: reflectors and optics
  • 90 mm overall axial length
  • 80 mm outer diameter
  • 50 mm clear opening
  • Anodized aluminum construction
  • Compatible with FLV-PL50, PL53A and SW50
  • Compatible with OP60(-20), OP61 and SLV-PL50

Add the specified anodized aluminum dust protection tube to a compatible reflector with a 50 mm clear optical opening.

Technical Specification Matrix

ParameterValue
Accessory groupReflectors and optics
Accessory familyReflectors; special reflectors
PurposeDust protection tube
CompatibilityFLV-PL50; PL53A; SW50; OP60(-20); OP61; SLV-PL50
MaterialAnodized aluminum
Tube length90 mm
Outer diameter80 mm
Clear opening50 mm
Dimensions L x W x H (cm)9 × 8 × 8
