1. Counting separated products at a transfer point
A transfer conveyor can present separated products to the axial optical axis and send PNP switching transitions to an external counter. The 270° potentiometer sets the reflected-light sensing condition for the representative product. Commissioning establishes actual surface response and spacing using the reference-target ranges, ≤2 ms resistive-load response and 250 Hz rating together with receiver timing.
Problem Solved
Product transitions provide external counting logic with arrival events, helping track transferred units when the installed optical presentation and product spacing create distinct switching states.
Product counting
PNP signal
250 Hz
2. Checking a component in a carrier pocket
An assembly fixture can position a carrier pocket at a repeatable inspection location and present the intended component to the axial optical axis. External inspection logic samples the configured PNP condition after the carrier settles. Reflected-light adjustment establishes the response to the intended component surface. Setup evaluates the pocket background and actual target remission.
Problem Solved
A component-reflection condition gives external inspection logic a presence reference at the presented pocket, helping identify an empty position before the next assembly operation.
Carrier inspection
Component presence
Infrared LED
3. Monitoring sheet continuity over a supported path
A sheet-handling machine can aim the axial sensor at a supported material surface and monitor its PNP state through external process logic. A break or missing sheet changes the returned-light condition at that fixed location. The installed gap and sensitivity are established using the 270° potentiometer, with trials covering actual sheet remission and the exposed background when material is absent.
Problem Solved
A maintained sheet-reflection condition lets external process logic recognize a loss of material at the monitored location, supporting continuity monitoring along a defined supported path.
Sheet continuity
Fixed sensing location
PNP output
