1. Counting separated products on a transfer conveyor
A conveyor can present separated products to the red LED sensing zone and send NPN transitions to an external counter. The four-turn potentiometer establishes the sensing distance, and the rotary switch selects light or dark signal behavior. Commissioning considers actual target remission and background position together with product spacing, the ≤0.5 ms response and 1,000 Hz rating.
Problem Solved
Product transitions provide external counting logic with arrival events, helping track separated units when the adjusted optical condition and spacing create distinct switching states.
Product counting
NPN output
1,000 Hz
2. Checking a component at a carrier inspection point
An assembly fixture can position a carrier pocket within the sensor’s working distance and present its intended component to the red LED beam. Background suppression supports a component-target arrangement ahead of a more distant background. External inspection logic samples the NPN state after the carrier settles, with setup evaluating actual surface remission and the selected light/dark behavior.
Problem Solved
A component-target switching condition gives external inspection logic a presence reference at the presented pocket, helping identify an empty location before the next operation.
Component inspection
Background suppression
NPN condition
3. Restoring sensing margin during machine changeover
During a machine changeover, a technician can present a representative product at its normal operating position and adjust the four-turn sensing-range potentiometer. The green stability LED and orange output LED provide separate local observations while the product and background are presented. The external controller then verifies the selected light/dark state through the NPN connection.
Problem Solved
Separate stability and output indications help setup personnel compare the adjusted sensing condition with the switching result, supporting repeatable checks using the representative product.
Changeover setup
Stability indication
Four-turn adjustment
