| Input Phases | 3 AC |
| Line Voltage | 380 ... 440 V +10% -20% |
| Line Frequency | 47 ... 63 Hz |
| Rated Current (LO) | 5.30 A |
| Output Phases | 3 AC |
| Rated Output Voltage | 400 V |
| Rated Power IEC 400V (LO) | 2.20 kW |
| Rated Current 400V (IN) | 5.60 A |
| Rated Current 380V (IN) | 5.60 A |
| Rated Output Current (LO) | 5.60 A |
| Max. Output Current | 6.20 A |
| Pulse Frequency | 4 kHz |
| Output Frequency for Vector Control | 0 ... 240 Hz |
| Output Frequency for V/f Control | 0 ... 550 Hz |
| Low Overload (LO) | 110% base load current IL for 60 s in a 600 s cycle time |
| Standard Digital Inputs Number | 6 |
| Standard Digital Inputs Switching Level 0 → 1 | 11 V |
| Standard Digital Inputs Switching Level 1 → 0 | 5 V |
| Standard Digital Inputs Max. Inrush Current | 15 mA |
| Fail-safe Digital Inputs Number | 0 |
| Digital Outputs as Relay Changeover Contact | 4 |
| Digital Outputs (Resistive Load) | DC 30 V, 1.0 A |
| Digital Outputs as Transistor | 0 |
| Analog / Digital Inputs Number | 2 (Differential input) |
| Analog / Digital Inputs Resolution | 12 bit |
| Switching Threshold as Digital Input 0 → 1 | 4 V |
| Switching Threshold as Digital Input 1 → 0 | 1.6 V |
| Analog Outputs Number | 2 (Non-isolated output) |
| PTC/KTY Interface Motor Temperature Sensor Input | 1 (PTC, KTY, PT1000 and Thermo-Click, accuracy ±5 °C) |
| Power Factor λ | 0.75 ... 0.93 |
| Power Factor cos φ 1 | 0.99 |
| Efficiency η | 0.97 |
| Sound Pressure Level (1m) | 55 dB |
| Power Loss | 0.093 kW |
| Filter Class (Integrated) | Unfiltered |
| EMC Category (with accessories) | without |
| Safety Function Safe Torque Off | without SIRIUS device (e.g. via S7-1500F) |
| Communication Protocols | USS, Modbus RTU, BACnet MS/TP |
| V/f Linear / Square-Law / Parameterizable | Yes |
| V/f with Flux Current Control (FCC) | Yes |
| V/f ECO Linear / Square-Law | Yes |
| Sensorless Vector Control | Yes |
| Vector Control, with Sensor | No |
| Encoderless Torque Control | Yes |
| Torque Control, with Encoder | No |
| Standard Board Coating Type | Class 3C2, according to IEC 60721-3-3: 2002 |
| Cooling | Air cooling using an integrated fan |
| Cooling Air Requirement | 0.005 m³/s (0.177 ft³/s) |
| Installation Altitude | 1,000 m (3,280.84 ft) |
| Operation Temperature | -20 ... 60 °C (-4 ... 140 °F) |
| Transport Temperature | -40 ... 70 °C (-40 ... 158 °F) |
| Storage Temperature | -40 ... 70 °C (-40 ... 158 °F) |
| Max. Operation Relative Humidity | 95% At 40 °C (104 °F), condensation and icing not permissible |
| Signal Cable Conductor Cross-Section | 0.15 ... 1.50 mm² (AWG 24 ... AWG 16) |
| Line Side Version | screw-type terminal |
| Line Side Conductor Cross-Section | 1.50 ... 2.50 mm² (AWG 16 ... AWG 14) |
| Motor End Version | screw-type terminals |
| Motor End Conductor Cross-Section | 1.50 ... 2.50 mm² (AWG 16 ... AWG 14) |
| DC Link PE Connection | On housing with M4 screw |
| Max. Motor Cable Length Shielded | 150 m (492.13 ft) |
| Max. Motor Cable Length Unshielded | 300 m (984.25 ft) |
| Degree of Protection | IP20 / UL open type |
| Frame Size | FSA |
| Compliance with Standards | CE, EAC, RCM, ROHS II |
| CE Marking | EMC Directive 2004/108/EC, Low-Voltage Directive 2006/95/EC |
| Converter Losses Efficiency Class | IE2 |
| Converter Losses Comparison with Reference Converter (90%/100%) | 33.8% |
| Physical Weight (kg) | 3.1 |
| Dimensions L x W x H (cm) | 20.9 x 7.3 x 23.2 |
