FOUNDATION Fieldbus positioner for linear/part-turn actuators; stainless-steel IP66/NEMA 4X enclosure, Ex i, double-acting.
SIPART PS2 Smart electropneumatic positioner for pneumatic linear and part-turn actuators, configured for FOUNDATION Fieldbus and Ex/nEx service. This exact order number specifies a stainless-steel enclosure with no inspection window, double-acting operation, intrinsic-safety protection, and threaded connections M20x1.5 electrical and G 1/4 pneumatic. Siemens identifies it as an active product with a net weight of 3.9 kg and no EAN/UPC available. Verified engineering data include IP66/NEMA 4X protection, actuator travel range 3 to 130 mm, rotation range 30 to 100°, supply air 1.4 to 7 bar, and operating temperature class data from the SIPART PS2 technical specifications.
| Parameter | Value |
|---|---|
| Article number | 6DR5622-0EG00-0AA0 |
| Product family | SIPART PS2 |
| Communication | FOUNDATION Fieldbus |
| Explosion protection | Intrinsic safety (Ex i) |
| Actuation type | Double-acting |
| Enclosure material | Stainless steel |
| Inspection window | No window |
| Electrical connection thread | M20x1.5 |
| Pneumatic connection thread | G 1/4 |
| Degree of protection | IP66 / NEMA 4X |
| Linear actuator travel range | 3 to 130 mm |
| Part-turn actuator angle range | 30 to 100° |
| Supply air pressure | 1.4 to 7 bar |
| Net weight | 3.900 kg |
| EAN | Not available |
| UPC | Not available |
Positions control valves on hydrocarbon process lines where intrinsic safety and IP66/NEMA 4X enclosure protection are required.
Prevents unsafe electrical ignition risk while maintaining stable valve positioning in corrosive, washdown-prone areas.
Drives pneumatic linear actuators on feed and dosing valves in chemically aggressive environments using a stainless-steel enclosure.
Maintains reliable actuation and communication where moisture, vapor, and corrosion can degrade standard positioners.
Controls part-turn actuators on isolation and changeover valves with the 30 to 100° rotation range and 1.4 to 7 bar supply air.
Provides precise part-turn positioning for quarter-turn valves without oversizing the air supply system.
