1. Evaluating safety inputs in a machine control arrangement
A machine designer can use the main module to evaluate four safety inputs and provide configured safety outputs within a Flexi Classic arrangement. Rotary-switch configuration establishes the intended logic and restart behavior. Commissioning validates the connected devices, input combinations, output response and external device monitoring against the complete machine safety requirement.
Problem Solved
Configured safety-input evaluation gives the control design a basis for responding to connected protective devices, with restart and output behavior established for the validated machine arrangement.
Safety input evaluation
Main module
Rotary configuration
2. Supervising restart with external device feedback
A machine-control arrangement can use the main module’s external device monitoring and configurable restart interlock to evaluate feedback and the selected restart condition. The system designer establishes the connected output devices and feedback circuit for the intended sequence. Commissioning validates feedback transitions, manual or automatic restart behavior and restoration of the complete machine safety function.
Problem Solved
Feedback evaluation and configured restart behavior help the control design supervise external devices before resuming the machine sequence, with the installed circuit validated for its intended operation.
External device monitoring
Restart interlock
Feedback supervision
3. Evaluating a material-transfer muting configuration
A material-transfer station can use the main module’s muting function within a configured Flexi Classic arrangement, with the documented zero-or-two muting-sensor option selected for the design. The system designer establishes sensor placement, signal evaluation and the permitted transfer condition. Commissioning validates the resulting behavior, including foreseeable access conditions and restoration of the protective function, for the complete machine installation.
Problem Solved
Muting functionality provides a basis for configured material-transfer logic, with the sensor arrangement and restoration of protective behavior established by the validated machine application.
Muting configuration
Material transfer
Protective behavior
