6 mm DIN-rail current-loop isolator with 24 VDC supply, 3-way isolation, 3 kV test voltage, and 0(4)–20 mA in/out.
6 mm DIN-rail current-loop isolator with 24 VDC supply, 3-way isolation, 3 kV test voltage, and 0(4)–20 mA in/out.
| Parameter | Value |
|---|---|
| Product type | Isolation amplifier / signal conditioner |
| Input signal range | 0(4) … 20 mA |
| Output signal range | 0(4) … 20 mA |
| Supply voltage | 24 VDC |
| Electrical isolation | 3-way |
| Test voltage | 3 kV |
| Module width | 6 mm |
| Mounting type | DIN-35 rail |
| Weight | 36.1 g |
| Height | 94 mm |
| Depth from upper edge of DIN rail | 97.8 mm |
| Input resistance (current input) | ≤ 50 Ω |
| Input current (max.) | 50 mA |
| Input voltage (max.) | 30 V |
| Operating temperature | -25 … 70 °C |
| Storage temperature | -40 … 85 °C |
| Relative humidity | 5 … 95 % (no condensation) |
| Operating altitude (max.) | 2000 m |
| Physical Weight (kg) | 0.04 |
| Dimensions L x W x H (cm) | 9.7 x 0.6 x 9.4 |
Used between field transmitters and PLC analog inputs to break ground loops while preserving a 4–20 mA process signal over a 24 VDC powered interface module.
Prevents ground-loop errors and signal corruption in long analog current loops.
Ideal for routing current signals between separately grounded cabinet sections where electrical isolation is required but the signal must remain current-loop compatible.
Maintains signal integrity across different grounding domains.
Appropriate for noisy industrial environments where shielded current signals need amplification and galvanic isolation before reaching controllers or recorders.
Improves immunity to electrical noise and interference on analog measurement lines.
