Weidmuller PRO ECO3 480W 24V 20A DIN Rail Power Supply

Technical Overview

480W DIN rail switch-mode power supply with 3-phase AC/DC input, providing 24V DC (22-28V adjustable) at 20A. IP20 rated.

Key Features

High efficiency of 92.2%.
Adjustable output voltage from 22 V to 28 V DC via potentiometer.
Three-phase AC input (3 x 320-575 V AC) and DC input (450-800 V DC) capability.
Compact design for space-constrained applications.
Operating temperature range from -25 °C to 70 °C.
Screw connection system for input and output.
Integrated protection against short-circuit, overload, and overheating.
IP20 protection degree.
Compatible with DC UPS, electronic load monitoring, and diode modules.
Features DC-OK LED and output voltage correctness indication (NO contact).
Parallel connection option available.

Technical Specification Matrix

Parameter	Value
Input Voltage AC Range	3 x 320...575 V AC / 2 x 360...575 V AC
Input Voltage DC Range	450...800 V DC
Output Voltage	24 V DC (adjustable 22-28 V DC)
Output Current	20 A
Output Power	480 W
Efficiency	92.2%
Frequency	45...65 Hz
Operating Temperature	-25 °C...70 °C
Storage Temperature	-40 °C...85 °C
Humidity	5…95 % rel. humidity, no condensation
IP Rating	IP20
Connection System	Screw connection
Mounting	DIN rail TS35
Mains Failure Bridge-over Time (min.)	20 ms (at 400V input), 21 ms (at 500V input)
Short-circuit Protection	Yes
Overload Protection	Yes
Over-heating Protection	Yes
Protection against Reverse Voltages from Load	30…35 V DC
Max. Residual Ripple	< 50 mVPP / bandwidth 20 MHz
Parallel Connection Option	Yes
Physical Weight (kg)	1.17
Dimensions L x W x H (cm)	12.5 x 6 x 13
