WTB4S-3P3234H Miniature Photoelectric Sensors – SICK Sensor

$ 368.50

SKU SICK 1048097 Category SICK W4S-3 Inox Hygiene

SICK sensor one of the world’s leading producers of sensors and sensor solutions for industrial applications. SICK is a technology and market leader in Factory and Logistics Automation as well as Process Automation. The sensor range are: Laser Sensors, Cylinder Sensors, Photoelectric Sensors, Fork Sensors, Encoders, Color Sensors, Distance Sensor, Contrast Sensor, Color Sensor, Inductive Proximity Sensors, Fiber Optic Sensor with our signature range sick sensor intelligence.

Part Number:1048097
Photoelectric Sensor Model:WTB4S-3P3234H
OEM Spec Ref

Features

Sensor/ detection principle	Photoelectric proximity sensor, Background suppression
Dimensions (W x H x D)	15.3 mm x 48.5 mm x 22.3 mm
Housing design	Hygiene
Housing design (light emission)	Rectangular
Sensing range max.	4 mm … 120 mm ¹⁾
Type of light	Visible red light
Light source	PinPoint LED ²⁾
Light spot size (distance)	Ø 2.5 mm (50 mm)
Wave length	650 nm
Adjustment	Cable ³⁾ Single teach-in button
Special applications	Hygienic and washdown zones

¹⁾ Object with 90 % reflectance (referred to standard white, DIN 5033).
²⁾ Average service life: 100,000 h at T_U = +25 °C.
³⁾ External teach-in: pulse > 2 s with voltage Uv with PNP and M with NPN.

Mechanics/electronics

Supply voltage	10 V DC … 30 V DC ¹⁾
Ripple	< 5 V_pp ²⁾
Current consumption	30 mA ³⁾
Switching output	PNP
Switching mode	Light switching
Output current I_max.	≤ 100 mA
Response time	< 0.5 ms ⁴⁾
Switching frequency	1,000 Hz ⁵⁾
Connection type	Cable with M8 male connector, 4-pin, 150 mm ⁶⁾ ⁷⁾
Mechanical connection	M12 adapter thread
Cable material	PVC
Circuit protection	A ⁸⁾ B ⁹⁾ C ¹⁰⁾
Protection class	III
Weight	40 g
Housing material	Stainless steel, Stainless steel V4A (1.4404, 316L)
Optics material	Plastic, PMMA
Enclosure rating	IP66 IP67 IP69K
Ambient operating temperature	–30 °C … +70 °C ¹¹⁾ –30 °C … +60 °C
Ambient temperature, storage	–30 °C … +75 °C
UL File No.	FDA, UL No. NRKH.E181493 & cUL No. NRKH7.E181493
